CPU - Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel®Celeron® processors in the LGA1150 package
- L3 cache varies with CPU
Chipset - Intel® H81 Express Chipset
Bộ nhớ - 2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
- Dual channel memory architecture
- Support for DDR3 1600/1333 MHz memory modules
- Support for non-ECC memory modules
- Support for Extreme Memory Profile (XMP) memory modules
Card đồ họa tích hợp Integrated Graphics Processor - Intel® HD Graphics support:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200
- Maximum shared memory of 1 GB
Âm thanh - Realtek® ALC887 codec
- High Definition Audio
- 2/4/5.1/7.1-channel
LAN - Realtek® GbE LAN chip (10/100/1000 Mbit)
Khe cắm mở rộng - 1 x PCI Express x16 slot, running at x16
- 2 x PCI Express x1 slots
Giao diện lưu trữ Chipset:
- 2 x SATA 6Gb/s connectors (SATA3 0/1) supporting up to 2 SATA 6Gb/s devices
- 2 x SATA 3Gb/s connectors (SATA2 2/3) supporting up to 2 SATA 3Gb/s devices
USB Chipset:
- Up to 2 USB 3.0/2.0 ports on the back panel
- Up to 6 USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Kết nối I/O bên trong - 1 x 24-pin ATX main power connector
- 1 x 4-pin ATX 12V power connector
- 2 x SATA 6Gb/s connectors
- 2 x SATA 3Gb/s connectors
- 1 x CPU fan header
- 1 x system fan header
- 1 x front panel header
- 1 x front panel audio header
- 2 x USB 2.0/1.1 headers
- 1 x Clear CMOS jumper
Kết nối bảng phía sau - 1 x PS/2 mouse port
- 1 x PS/2 Keyboard port
- 1 x parallel port
- 1 x serial port
- 1 x D-Sub port
- 2 x USB 3.0/2.0 ports
- 2 x USB 2.0/1.1 ports
- 1 x RJ-45 port
- 3 x audio jacks (Line In, Line Out, Mic In)
Điều khiển I/O - iTE® I/O Controller Chip
Theo dõi phần cứng - System voltage detection
- CPU/System temperature detection
- CPU/System fan speed detection
- CPU/System overheating warning
- CPU/System fan fail warning
- CPU/System fan speed control
BIOS - 2 x 64 Mbit flash
- Use of licensed AMI EFI BIOS
- Support for DualBIOS™
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Tính năng duy nhất - Support for Q-Flash
- Support for Xpress Install
- Support for APP Center
- Support for ON/OFF Charge
Gói phần mềm - Norton® Internet Security (OEM version)
Hệ điều hành - Support for Windows 10/8.1/8/7
Hệ số khuôn - Micro ATX Form Factor; 22.6cm x 17cm
Ghi chú - Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
- Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
